YN15V00037S015 Kobelco SK210SRLC SK210LC-8 Excavator COUPLING
Original price was: $80.00.$60.00Current price is: $60.00.
Number: YN15V00037S015
Type: COUPLING
Engine: –
Utend: SK210LC-8 SK210SRLC
Place of Origin:China/Japan
Packing: Fumigate Seaworthy Packing
Engine Brand: ISUZU/HINO/MISTUBISHI
Excavator Brand: KOBELCO/HITACHI
Number: YN15V00037S015
Type: COUPLING
Utend: SK200-8 SK210D-8
Place of Origin:China/Japan
Packing: Fumigate Seaworthy Packing
Engine Brand: ISUZU/HINO/MISTUBISHI
Excavator Brand: KOBELCO/HITACHI
编号(REF) | 数量(Qty) | 件号(Part No) | 品名(Part Name) |
1 | YN15V00037R460 | REPAIR KIT Repair Kit Consists Of Ref. 107×1, 108×1 (F2 Only) | |
1 | YN15V00037R450 | SEAL KIT Repair Kit Consists Of Ref. 31×3, 132×1, 135×1, 139×1, 329×2, 369×2, 371×2, 375×6, 379×1, 380×1 | |
1 | YN15V00037R440 | VALVE Repair Kit Consists Of Ref. 323×1, 326×2, 327×2, 328×2, 331×2 | |
1 | YN15V00037R420 | PLATE Repair Kit Consists Of Ref. 103×1, 167×2 | |
1 | YN15V00037R410 | PISTON Repair Kit Consists Of Ref. 161×1, 163×1 | |
1 | YN15V00037R400 | PISTON Repair Kit Consists Of Ref. 105×9, 106×9 | |
399 | 1 | YN15V00037S399 | Name Plate |
398 | 4 | YN15V00037S398 | Rivet |
397 | 1 | 2483U254S19 | Name Plate |
380 | 1 | YN15V00037S380 | O-RING |
379 | 1 | ZD12P01600 | O-RING |
378 | 3 | YN15V00017S026 | SPRING |
377 | 3 | YN15V00017S017 | CHECK VALVE |
376 | 3 | GN15V00010S024 | RESTRICTOR |
375 | 6 | ZD12P00800 | O-RING |
374 | 5 | YN15V00017S038 | PLUG |
373 | 2 | LC15V00023S068 | SPRING |
372 | 2 | LC15V00023S067 | RESTRICTOR |
371 | 2 | ZD12P01400 | O-RING |
370 | 1 | LC15V00023S062 | PLUG |
369 | 2 | ZD12P01100 | O-RING |
368 | 2 | 2436U1317S13 | PLUG |
367 | 1 | 2436R874S5 | SPRING SEAT |
366 | 1 | 2436R874S7 | SPRING |
365 | 1 | 2436R874S6 | PIN |
364 | 1 | 2436R874S3 | FLEXIBLE JOINT Connector |
363 | 1 | YN15V00037S363 | SPOOL |
345 | 15 | 2436U1427S25 | PLUG |
343 | 8 | ZS23C16040 | SCREW Cap |
341 | 1 | YN15V00017S033 | PIN |
331 | 2 | NSS | NOT SERVICED SEPARATELY O-ring |
330 | 2 | YN15V00037S330 | SPRING |
329 | 2 | YN15V00037S329 | O-RING |
328 | 2 | NSS | NOT SERVICED SEPARATELY Spring |
327 | 2 | NSS | NOT SERVICED SEPARATELY Valve |
326 | 2 | NSS | NOT SERVICED SEPARATELY Plug |
325 | 2 | YN15V00037S325 | SEAT Spring |
324 | 2 | YN15V00037S324 | PLUG |
323 | 1 | NSS | NOT SERVICED SEPARATELY Spool |
301 | 1 | YN15V00037S301 | FLANGE |
200 | 2 | YN22V00036F1 | VALVE Assy, Relief (See HC385) |
167 | 2 | NSS | NOT SERVICED SEPARATELY Pivot |
163 | 1 | NSS | NOT SERVICED SEPARATELY Seal |
162 | 1 | YN15V00037S162 | BALL |
161 | 1 | NSS | NOT SERVICED SEPARATELY Piston |
150 | 1 | YN15V00037S150 | BEARING Roller |
149 | 1 | YN15V00037S149 | BEARING Roller |
139 | 1 | YN15V00037S139 | RING |
138 | 1 | 2436U1749S17 | PLUG |
137 | 1 | 2436U279S3 | PLUG |
135 | 1 | YN15V00037S135 | RING |
133 | 1 | YN15V00009S019 | RING Retaining |
132 | 1 | YN15V00009S027 | OIL SEAL |
119 | 1 | YN15V00037S119 | SHIM |
116 | 4 | YN15V00037S116 | PLATE Separator |
115 | 3 | YN15V00037S115 | PLATE Friction |
114 | 9 | YN15V00037S114 | SPRING |
113 | 8 | YN15V00037S113 | SPRING |
112 | 1 | YN15V00037S112 | PISTON |
109 | 1 | YN15V00037S109 | PLATE |
1 | YN15V00037S099 | Ball[ (For F2 ONLY) | |
108 | 1 | YN15V00037S108 | BALL Joint (For F1 ONLY) |
1 | YN15V00037S098 | PLATE Retainer (For F2 ONLY) | |
107 | 1 | YN15V00037S107 | PLATE Retainer (For F1 ONLY) |
106 | 9 | NSS | NOT SERVICED SEPARATELY Shoe |
105 | 9 | NSS | NOT SERVICED SEPARATELY Piston |
104 | 1 | YN15V00037S104 | CYLINDER Block |
103 | 1 | NSS | NOT SERVICED SEPARATELY Plate, Shoe |
102 | 1 | YN15V00037S102 | SHAFT |
101 | 1 | YN15V00037S101 | SPINDLE |
36 | 1 | ZR26X03200 | SNAP RING Retaining |
35 | 18 | ZS23C10035 | SCREW Cap |
31 | 3 | ZD12P01800 | O-RING |
30 | 3 | 2441U995S121 | PLUG |
29 | 1 | YN15V00037S029 | SEAL Floating |
28 | 3 | YN15V00037S028 | BEARING Needle |
27 | 3 | YN15V00037S027 | BEARING Needle |
24 | 2 | YN15V00037S024 | BALL BEARING Ball |
23 | 1 | YN15V00037S023 | SHIM |
22 | 2 | YN15V00037S022 | HALF-RING Lock Washer |
17 | 3 | YN15V00037S017 | PIN |
16 | 3 | YN15V00037S016 | PIN |
15 | 1 | YN15V00037S015 | COUPLING |
14 | 1 | YN15V00037S014 | COVER |
13 | 1 | YN15V00037S013 | PLATE |
12 | 6 | YN15V00037S012 | WASHER Thrust |
11 | 6 | YN15V00037S011 | WASHER Thrust |
10 | 3 | YN15V00037S010 | PIN |
9 | 3 | YN15V00037S009 | GEAR Planetary |
8 | 1 | YN15V00037S008 | GEAR Sun |
7 | 1 | YN15V00037S007 | GEAR Carrier |
6 | 3 | YN15V00037S006 | PIN |
5 | 3 | YN15V00037S005 | GEAR Planetary |
4 | 1 | YN15V00037S004 | GEAR Sun |
3 | 1 | YN15V00037S003 | FLANGE Carrier |
1 | 1 | YN15V00037S001 | HUB |
AR | YN15V00037F2 | HYDRAULIC MOTOR Assy (propelling) | |
AR | YN15V00037F1 | HYDRAULIC MOTOR (propelling) | |
1 | YN15V00037R430 | VALVE Repair Kit Consists Of Ref. 103×1, 323×1, 324×2, 325×2, 326×2, 327×2, 328×2, 329×2, 330×2, 331×2, 341×1, 343×8, 345×15, 363×1, 364×1, 365×1, 366×1, 367×1, 368×2, 369×2, 370×1, 371×2, 372×2, 373×2, 374×5, 375×6, 376×3, 377×3, 378×3, 379×1, 380×1 |
