YW10V00003S111 Genuine Japan Kawasaki Hydraulic Pump SHAFT
Original price was: $80.00.$60.00Current price is: $60.00.
Number: YW10V00003S111
Type: SHAFT
Engine: –
Utend: SK100L SK120-5 SK120LC-5
Place of Origin:China/Japan
Packing: Fumigate Seaworthy Packing
Engine Brand: ISUZU/HINO/MISTUBISHI
Excavator Brand: KOBELCO/HITACHI
Number: YW10V00003S111
Type: SHAFT
Utend: SK100L SK120-5 SK120LC-5
Place of Origin:China/Japan
Packing: Fumigate Seaworthy Packing
Engine Brand: ISUZU/HINO/MISTUBISHI
Excavator Brand: KOBELCO/HITACHI
编号(REF) | 数量(Qty) | 件号(Part No) | 品名(Part Name) |
2 | YW10V00003S520 | PIN PIN ASSY,CONSISTS OF REF 531,548 | |
2 | YW10V00003S210 | PLATE PLATE ASSY 212,214 | |
1 | 2437U188S14 | REPAIR KIT (L H ),CONSISTS OF REF 141,314 | |
1 | 2437U188S13 | REPAIR KIT (R H ),CONSISTS OF REF 141,313 | |
2 | YW10V00003S011 | PISTON ASSY CONSISTS OF REF 151,152 | |
983 | 2 | 2437U407S983 | RIVET |
981 | 1 | 2437U407S981 | LABEL NAME PLATE |
953 | 4 | YW10V00003S953 | SETSCREW |
888 | 2 | YW10V00003S888 | PIN |
826 | 1 | ZR26X09500 | SNAP RING Retaining — ID 95 x OD 98.5 x Th 3.0mm |
727 | 2 | ZD12P01400 | O-RING ID 13.80 ± 0.19 x OD 18mm |
726 | 8 | ZD12P00900 | O-RING ID 08.80 ± 0.17 x OD 12mm |
710 | 2 | ZD12C09500 | O-RING(G95 1B) |
708 | 4 | ZD12P00700 | GASKET O-Ring — ID 06.80 ± 0.16 x OD 10mm |
535 | 2 | YW10V00003S535 | STOPPER |
534 | 2 | YW10V00003S534 | STOPPER |
532 | 2 | YW10V00003S532 | PISTON |
531 | 2 | NSS | NOT SERVICED SEPARATELY PIN |
530 | 2 | YW10V00003S530 | |
508 | 2 | YW10V00003S508 | SETSCREW |
490 | 11 | 2441U722S490 | PLUG 1/16″ NPTF |
468 | 1 | YW30V00001S155 | PLUG 1/2″ |
467 | 2 | YN30V00001S156 | PLUG |
466 | 2 | YN30V00001S157 | PLUG |
408 | 12 | ZS23C12030 | SCREW M12x1.75x30mm |
407 | 4 | ZS23C06045 | SCREW M06x1.0x45mm |
406 | 4 | ZS23C06030 | SCREW M06x1.0x30mm |
401 | 6 | YW10V00003S401 | CAPSCREW |
363 | 2 | YW10V00003S363 | SUCTION PIPE PIPE,SEAL |
312 | 1 | YW10V00003S312 | BLOCK, VALVE |
272 | 1 | YW10V00003S272 | CASE |
271 | 1 | YW10V00003S271 | CASE |
263 | 1 | YW10V00003S263 | COVER |
261 | 1 | YW10V00003S261 | COVER |
251 | 2 | YW10V00003S251 | SUPPORTING ARM SUPPORT |
211 | 2 | 2437U188S211 | PLATE PLATE, SHOE |
158 | 2 | 2437U188S158 | THRUST RING SPACER |
157 | 18 | 2437U188S157 | SPRING |
156 | 2 | 2437U188S156 | BUSHING BUSHING |
153 | 2 | 2437U188S153 | PLATE |
127 | 3 | YW10V00003S127 | SPACER |
123 | 2 | YW10V00003S123 | BEARING, ROLLER |
114 | 1 | YW10V00003S114 | COUPLING COUPLING |
113 | 1 | YW10V00003S113 | SHAFT |
111 | 1 | YW10V00003S111 | SHAFT SHAFT |
LP10V00002F1 | PUMP ASSY | ||
124 | 2 | 2437U188S124 | BEARING NEEDLE |
983 | 2 | 2437U407S983 | RIVET |
981 | 1 | YX10V00003S981 | NAME PLATE |
954 | 2 | 2437U188S954 | SCREW |
953 | 2 | 2437U188S953 | CAP |
901 | 2 | ZS91C01000 | BOLT Eye — M10x1.50x18mm |
886 | 4 | ZP26D06014 | PIN Roll — OD 06 x 14mm Long |
885 | 2 | 2441U436S886 | PIN |
824 | 2 | ZR16X03500 | RING Retaining — ID 32.20 x OD 35 x Th 1.6mm |
808 | 4 | ZN18C16010 | NUT M16x2.0mm |
792 | 2 | ZD85G03000 | BACK-UP RING ID 30 x OD 35 x Th 1.25mm |
789 | 2 | ZD85P01600 | RING |
774 | 1 | YX10V00003S774 | OIL SEAL |
732 | 2 | YW10V00003S732 | O-RING |
728 | 4 | YT10V00003S708 | O-RING |
727 | 2 | YN10V01001S727 | GASKET |
725 | 2 | YT10V00003S710 | O-RING |
724 | 18 | YX10V00003S015 | O-RING |
719 | 2 | YX10V00003S014 | GASKET O-RING |
717 | 2 | YX10V00003S013 | GASKET O-RING |
711 | 1 | YX10V00003S012 | O-RING |
710 | 2 | YX10V00003S011 | O-RING O-RING |
702 | 2 | YW10V00003S702 | O-RING |
548 | 2 | NSS | NOT SERVICED SEPARATELY PIN (PART OF KIT) |
535 | 2 | 2437U188S535 | STOP |
534 | 2 | YX10V00003S534 | STOP |
532 | 2 | YX10V00003S532 | PISTON |
531 | 2 | NSS | NOT SERVICED SEPARATELY PIN (PART OF KIT) |
530 | 1 | 2437U188S530 | REPAIR KIT REPAIR KIT INCLUDES 531, 548) |
490 | 15 | 2441U722S490 | PLUG 1/16″ NPTF |
468 | 2 | YN30V00001S156 | PLUG |
467 | 4 | 2441U667S468 | PLUG |
466 | 2 | 2441U667S466 | PLUG 1/4″ PF |
406 | 8 | ZS23C06016 | SCREW M06x1.0x16mm |
401 | 8 | 2437U188S401 | SCREW |
314 | 1 | NSS | NOT SERVICED SEPARATELY PLATE (PART OF KIT) |
313 | 1 | NSS | NOT SERVICED SEPARATELY PLATE (PART OF KIT) |
312 | 1 | YX10V00003S312 | BLOCK |
271 | 2 | 2437U188S271 | CASING |
262 | 1 | YX10V00003S262 | COVER |
261 | 1 | 2437U188S261 | COVER |
252 | 1 | YX10V00003S252 | SUPPORT |
251 | 1 | 2437U188S251 | PLATE |
211 | 2 | 2437U188S211 | PLATE |
157 | 18 | 2437U188S157 | SPRING |
156 | 2 | YW10V00005S156 | BUSHING |
123 | 2 | YB10V00004S123 | BEARING |
116 | 1 | YX10V00003S116 | GEAR |
113 | 1 | YX10V00003S113 | SHAFT |
111 | 1 | YX10V00003S111 | SHAFT |
30 | 1 | 2437U412S210 | REPAIR KIT (INCLUDES 212, 214) |
14 | 1 | YX10V00003R300 | REPAIR KIT (INCLUDES 141, 314) |
13 | 1 | YX10V00003R200 | REPAIR KIT (INCLUDES 141, 313) |
11 | 1 | YB10V00004R100 | REPAIR KIT (INCLUDES 151, 152) |
AR | YM10V00002F2 | PUMP, HYD | |
124 | 2 | YW10V00005S124 | BEARING |
1 | YX10V00003R400 | REPAIR KIT CONSISTS OF ITEM 212X1, 214X1 | |
808 | 4 | ZN12C16010 | NUT |
792 | 2 | ZD85G03000 | BACK-UP RING ID 30 x OD 35 x Th 1.25mm |
789 | 2 | ZD85P01600 | RING BACK UP |
774 | 1 | YX10V00003S774 | OIL SEAL |
732 | 2 | ZD12P01600 | O-RING ID 15.80 ± 0.20 x OD 20mm, (FOR F1 Only) |
728 | 4 | ZD12P01800 | O-RING ID 17.80 ± 0.21 x OD 22mm, (FOR F1 Only) |
725 | 2 | ZD12P01100 | O-RING ID 10.80 ± 0.18 x OD 15mm, (FOR F1 Only) |
724 | 18 | ZD12P00800 | O-RING ID 07.80 ± 0.16 x OD 11mm, (FOR F1 Only) |
719 | 2 | ZD12G11500 | O-RING ID 114.40 ± 0.94 x OD 120mm, (FOR F1 Only) |
717 | 2 | ZD12G12000 | GASKET O-Ring — ID 119.40 ± 0.98 x OD 125mm, (FOR F1 Only) |
711 | 1 | ZD12G09500 | GASKET O-Ring — ID 94.40 ± 0.81 x OD 100mm, (FOR F1 Only) |
710 | 2 | ZD12G08500 | O-RING ID 84.40 ± 0.73 x OD 90mm, (FOR F1 Only) |
702 | 2 | ZD12G03000 | O-RING ID 29.4 ± 0.29 x OD 35mm, (FOR F1 Only) |
467 | 4 | 2441U436S468 | PLUG |
123 | 2 | YX10V00003S123 | ROLLER BEARING |
AR | YX10V00003F2 | HYDROSTATIC PUMP PUMP ASSY | |
AR | YX10V00003F1 | HYDRAULIC PUMP PUMP ASSY (Not serviced – Order next higher assembly pn) | |
153 | 2 | 2437U188S153 | PLATE |
