LS02P00085F1 LS02P00031F1 HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator

LS02P00085F1 LS02P00031F1 HINO P11C DIESEL ENGINE Assembly

Original price was: $30,000.00.Current price is: $28,888.00.

Number: LS02P00085F1 LS02P00031F1
Type: HINO P11C DIESEL ENGINE Assembly
Utend:Kobelco SK460-8 SK485-8
Place of Origin:China/Japan
Packing: Fumigate Seaworthy Packing
Engine Brand: ISUZU/HINO/MISTUBISHI
Excavator Brand: KOBELCO/HITACHI

Inquiry
1 Step 1
Contact Us
keyboard_arrow_leftPrevious
Nextkeyboard_arrow_right
SKU: LS02P00085F1 Categories: , , , ,
Product Description

LS02P00042F1  LS02P00085F1 LS02P00031F1 HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator

Number: LS02P00085F1
Type: DIESEL ENGINE ASSY
Utend: Kobelco SK460-8 SK485-8
Place of Origin:China/Japan
Packing: Fumigate Seaworthy Packing
Engine Brand: ISUZU/HINO/MISTUBISHI
Excavator Brand: KOBELCO/HITACHI

LS02P00085F1 LS02P00031F1 HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator
LS02P00085F1 LS02P00031F1 LS02P00042F1  HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator
LS02P00085F1 LS02P00031F1 HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator
LS02P00085F1 LS02P00031F1 LS02P00042F1  HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator

LS02P00085F1 LS02P00031F1 HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator
LS02P00085F1 LS02P00031F1 LS02P00042F1  HINO P11C Assembly DIESEL ENGINE ASSY EA-P11C-TI Used for Kobelco SK460-8 SK485-8 Excavator
1 VHS040104264A KIT Gasket Kit (Engine Overhaul), See Figure 09-29
1 Engine Accessory Parts, See Figure 09-28, Not Shown
1 VH28100E0010 STARTER MOTOR Starter Motor Assembly, See Figure 09-27
1 VH27060E0190 ALTERNATOR Alternator W/Regulator Assembly, See Figure 09-26
1 Turbocharger, See Figure 09-25
Engine Electrical Parts, See Figure 09-24
1 Engine Electrical Parts, See Figure 09-23
Cooling System, See Figure 09-22
1 Cooling System, See Figure 09-21
1 VH225701790A FUEL PUMP Fuel Priming Pump & Fuel Feed Pump, See Figure 09-20, Not Shown
1 VH233002700B FILTER ASSY Fuel Filter Assembly, See Figure 09-19, Not Shown
1 Fuel System, See Figure 09-17 & 09-18
1 VH151102124A PUMP Oil Pump Assembly, See Figure 09-16, Not Shown
1 VH15710E0040 OIL COOLER Oil Cooler, See Figure 09-15
1 VH15600E0070 ENGINE OIL FILTER Oil Filter Assembly, See Figure 09-14, Not Shown
1 Lubrication, See Figure 09-13
1 Intake & Exhaust System, See Figure 09-11 & 09-12
1 Intake & Exhaust System, See Figure 09-09 & 09-10
1 Valve System, See Figure 09-08, Not Shown
1 Camshaft and Idler Gear, See Figure 09-07, Not Shown
1 Main Moving Parts, See Figure 09-06
1 Timing Gear Cover & Flywheel Housing, See Figure 09-05
1 Engine Cylinder Block, See Figure 09-03 & 09-04
1 Engine Cylinder Head, See Figure 09-01 & 09-02
1 LS02P00031F1 ENGINE ASSY
1 PY01P01043D3 CLIP Wire Ties — 188mm Long
1 YN13E01375P1 CLIP Anchor Wire Ties
12 ZW16H08000 WASHER ID 08 x OD 18 x Th 3.2mm
6 ZN18C08007 NUT M08x1.25mm
6 ZW16H10000 WASHER ID 11 x OD 24 x Th 3.2mm
6 ZN18F10008 NUT M10x1.25mm
1 LC75S00003P1 FAN
1 LS41C00013P1 STEP
2 PY01P01043D8 CLIP Wire Ties — 368mm Long
1 HX81X15170DX TUBE ID 15.2 x OD 19.5 x 1700mm Long (66-59/64 in)
1 ZC46X19011 CLIP Clamp, Single Line — ID 19.1 x 42mm Long
1 ZM22C10065 BOLT M10x1.50x65mm (Incls. Washer & Lockwasher)
1 ZM73C10020 BOLT M10x1.50x20mm (Incls. Washer)
4 ZM73C10025 BOLT M10x1.50x25mm (Incls. Washer)
4 ZM73C12030 BOLT M12x1.75x30mm (Incls. Washer)
16 ZW16H14000 WASHER ID 15 x OD 29 x Th 3.2mm
10 ZW16H12000 WASHER ID 13 x OD 26 x Th 3.2mm
4 ZW16H27000 WASHER ID 28 x OD 56 x Th 6.0mm
4 ZW16H18000 WASHER ID 19 x OD 36 x Th 4.5mm
2 ZN18C27022 NUT M27x3.0mm
2 ZN18C18015 NUT M18x2.5mm
16 ZS18C14045 CAP Screw — M14x2.0x45mm
10 ZS18C12050 SCREW M12x1.75x50mm
2 ZS18C27170 SCREW M27x3.0x170mm
2 ZS18C18150 CAP Screw — M18x2.50x150mm
1 YN02P01125P1 CLAMP
2 YN02P01076P1 BUSHING
1 LS02P01096P1 BRACKET
2 LS02P01047P1 PLATE
2 YN02P01088P1 PLATE
2 LS02P01105P1 COVER
2 LS02P01104P1 COVER
4 LS02P01044P2 RUBBER MOUNTING
4 LC02P01049P1 MOUNTING PARTS Rubber
1 LS02P01144P1 BRACKET
1 LS02P01142P1 BRACKET
1 LS02P01156P1 BRACKET
1 LS02P01151P1 BRACKET
Engine Installation, LS02P00030F1, Incls, Refs. 10 – 59
Engine Installation, LS02P00029F1
1 LS02P00031F1 ENGINE ASSY See Figure 09-00
1 VH985512168B JOINT Joint, Pipe
2 VH985110139A O-RING O-Ring
2 VH985109127A O-RING O-Ring
7 VH985114102A O-RING O-Ring
1 VH985115103A O-RING O-Ring
1 VH985116101A O-RING O-Ring
1 VH965918105C WASHER Soft
1 VH965922118A WASHER Washer, Soft
1 VH965528140A PLUG Plug, Sealing
1 VH965518140A WASHER Plug, Sealing
1 VH965514140A BOLT Plug, Sealing
7 VH962910101B PLUG Plug
1 VH961018120A PLUG Plug
1 VH960014090A PLUG
2 VH950912103B PIN Pin
2 VH950410240A PIN Pin, Straight
1 VH950405160A PIN Pin, Straight
1 VH950308140A STRAIGHT PIN Pin, Straight
4 VH940112750A BOLT Bolt
2 VH924008087A NUT
40 VH919208452A BOLT Bolt, W/Washer
2 VH919110451A BOLT Bolt
15 VH919108201A BOLT Bolt
2 VH918108250A BOLT Bolt
2 VH918108200A BOLT Bolt
26 VH918108160A BOLT
12 VH902908106A BOLT Bolt
2 VH900129167A COLLAR Collar
2 VH900129116A COLLAR Collar
2 VH799042180A CLIP Assembly
2 VH799042450A CLIP Clip Assembly
1 VH296012000B PIPE Pipe Assembly, Oil
1 VH156021151A VALVE Valve Assembly, Oil Pressure
1 VH15301E0210 GAUGE Gauge Assembly, Oil Level
1 VH121513031A GASKET Gasket, Oil Pan
1 VH121491040A DRAIN VALVE Valve, Oil Drain
1 VH12111E0100 ENGINE OIL PAN Pan, Oil
1 VH114912410A BRACKET Bracket, Injector Pump
2 VH114531220A PLUG Plug Main Hole
2 VH114531210A PLUG Plug Main Hole
1 VH114531140A PLUG Plug Main Hole
1 VH114531030A PLUG Plug Main Hole
1 VH11452E0120 GUIDE Guide, Oil Level Gauge
1 VH114391030B PLATE Plate, Seal
1 VH11401E0720 CYLINDER BLOCK Block Assembly, Cylinder — See Figure 09-04
4 VH112651132A COVER Cover, Water Gallery
2 VH112511210A VALVE COVER Cover, Valve Push Rod
1 VH112071480A COVER ASSY Cover Assembly, Water Gallery
3 VH980006100A BALL Steel
1 VH965510100A WASHER Plug, Sealing
13 VH963940105A EXPANSION PLUG Plug, Expansion
1 VH963936106A EXPANSION PLUG Plug, Expansion
2 VH963324160A PLUG Plug, Sealing
12 VH963317120A PLUG Sealing
2 VH950410180A PIN Pin, Straight
4 VH950405080A PIN Pin, Straight
6 VH156051250B VALVE Assembly, Oil Check
1 VH118711050A CAMSHAFT BEARING Bearing, # 7 Camshaft
1 VH118611040A CAMSHAFT BEARING Bearing, # 6 Camshaft
1 VH118511050A CAMSHAFT BEARING Bearing, # 5 Camshaft
1 VH118411020A CAMSHAFT BEARING Bearing, # 4 Camshaft
1 VH118311060A CAMSHAFT BEARING Bearing, # 3 Camshaft
1 VH118211070A CAMSHAFT BEARING Bearing, # 2 Camshaft
1 VH118111070A CAMSHAFT BEARING Bearing, # 1 Camshaft
14 VH115211172B BOLT Bolt, Bearing Cap
6 VH114673150A LINER Liner, Service Size Cylinder
6 VH114673140A LINER Liner, Service Size Cylinder
6 VH114673130A LINER Liner, Service Size Cylinder
1 VH114531200A PLUG Plug Main Hole
6 VH114081310A PIPE Pipe Assembly, Oil Jet
1 VH11401E0720 CYLINDER BLOCK Block Assembly, Cylinder
6 VHS130BE0210 PISTON RING Set, Piston & Piston Ring
6 VHS1304E0100 PISTON RING SET Set, Piston Ring
12 VH981947114A RING Ring, Retainer
6 VH962913107A PLUG Plug
1 VH953207220A KEY Key
1 VH950408200A PIN Pin, Straight
2 VH950408180A PIN Pin, Straight
6 VH906810300A BOLT
6 VH900124511A BOLT Bolt
6 VH900124203A BOLT
1 VH135311162A GEAR Gear, Oil Pump Drive
1 VH135211430C GEAR Gear, Crankshaft
1 VH134715560A CRANKSHAFT PULLEY Pulley, Crankshaft
1 VH13471E0180 CRANKSHAFT PULLEY Pulley, Crankshaft
1 VH13470E0100 CRANKSHAFT PULLEY Pulley Assembly, Crankshaft
9 VH134551780B BOLT Bolt, Flywheel
1 VH134531290B RING GEAR Gear, Flywheel Ring
1 VH13450E0D30 FLYWHEEL Flywheel Assembly
1 VH134071671A DAMPER Damper Assembly, Crankshaft
1 VH134003373B CRANKSHAFT Crankshaft Assembly
6 VH132721350A BUSHING Bushing, Standard Connecting
12 VH132661170A NUT Nut, Connecting
12 VH132651521A BOLT Bolt, Connecting
6 VH132601590B CONNECTING ROD Rod Assembly, Connecting
1 VH132011880B BEARING SET Bearing Set, Standard Connecting Rod
1 VH117011851A BEARING SET Bearing Set, Standard Crankshaft
1 VH110111330A SET OF WASHERS Washer Set, Standard Crankshaft Thrust
1 VH040132116A PISTON PIN Kit, Piston Pin
1 VH040130229A PISTON RING Kit, Piston Ring & Liner
1 VH040130199A PISTON RING Kit, Piston Ring & Liner
1 VH040130198A PISTON RING Kit, Piston Ring & Liner
6 VH963922109A EXPANSION PLUG Plug, Expansion
1 VH963350160A PLUG
6 VH963330160A PLUG
10 VH963324160A PLUG Plug, Sealing
7 VH963322160A PLUG
6 VH950405100A PIN Pin, Sraight
6 VH900115183A GASKET Gasket
6 VH111761170B SEAT Seat, Injector Nozzle
12 VH111351760A VALVE SEAT Seat, Valve Exhaust
12 VH111311520A VALVE SEAT Seat, Valve Intake
24 VH111221190A BUSHING Bushing, Valve Guide Intake (Standard Repair)
1 VH111152810A CYLINDER HEAD GASKET Gasket
1 VH111014640D CYLINDER HEAD Cylinder Head Assembly
12 VHS1306E0010 ASSEMBLING ROD Rod Assembly, Valve Push
2 VH963018160A EXPANSION PLUG Plug, Expansion
24 VH921910107A NUT Nut
2 VH918106160A BOLT Bolt
6 VH900129222A COLLAR Collar
48 VH900126120A SPRING LOCK Lock, Valve Spring Retainer
12 VH900125222A BOLT Bolt
1 VH139512320B SUPPORT Support, Valve Rocker
5 VH139512290B SUPPORT Support, Valve Rocker
1 VH139512270B SUPPORT Support, Valve Rocker
1 VH139011260A SHAFT Shaft Assembly, Valve Rocker
6 VH138401410B ARM Arm Assembly, Valve Rocker Exhaust
6 VH138301620B ROCKER ARM Arm Assembly, Valve Rocker
12 VH137871400A SCREW Screw, Valve Adjuster
12 VH137871090B SCREW Screw, Valve Adjuster
24 VH137351360A VALVE SEAT Seat, Upper Valve Spring
24 VH137341260A VALVE SEAT Seat, Lower Valve Spring
24 VH137321420B VALVE SPRING Spring, Inner Valve
24 VH137311530B VALVE SPRING Spring, Outer Valve
12 VH137151860A VALVE Valve, Standard Exhaust
12 VH137111790A STD ENGINE INLET VALVE Valve, Standard Intake
12 VH137071260A VALVE Lifter Assembly, Valve
12 VH137061261A CROSS Crosshead Assembly
Valve System
Company Information

Gz wins contruction engineering company is engaged in development, production, marketing and agency services.
We are a manufacturer of specialization and diversification engineering machinery parts. Our products are selling well in America, Europe, Southeast Asia, the Middle East, Africa and other countries and regions.

We Provide Original Genuine Kobelco Parts,Include the following,Air-conditioning System,A/C Assembly, A/C Hose,A/C Compressor,A/C Condenser,Blower Assembly,Evaporator,A/C Pipe,A/C Receiver, A/C Filter.
Body & Stamping Parts,CAB Assy, Engine Mounting,Engine Hood, Car Body,Door Panel,Roof.
Hydraulics System,Set plate,Piston shoe,Cylinder block,Valve plate,Drive shaft,Ball guide,Piston pump,Gear pump.

We Provide Genuine MITSUBISHI HINO ISUZU Engine Parts

Hino：J05E, J08E, P11C.
Mitsubishi: D04FR,4M40,6D16,6D22,6D24,6D31,6D34.
Isuzu:4HK1,4JJ1,4LE1,4JB1,4BG1,6HK1,6WG1,6BG1,6UZ1,6BD1.
KOBELCO：SK60,SK75,SK130,SK140,SK200,-8,SK250,-8,SK330,SK460,SK485.
Engine Assy,Engine Gasket Kits,Camshaft,Sprocket Camshaft,Tensioner,Crankshaft,Crankshaft Pulley,Crankshaft Bearing,Valve,Valve Seat,Valve Arm,Rocker Cover,Valve Spring,Valve Guide,Cylinder Head,Cylinder Liner,Cylinder Block,Washer,Piston,Piston Pin,Piston Ring,Piston Liner,Flywheel,Ring Gear of Flywheel,Timing Chain/Belt,Connecting Rod,Connecting Rod Bearing,Rocker Arm Shaft,Valve Cotter,Thrust Washer.
Injection Fueling System,Air Cleaner,Air Cleaner Cover,Exhaust Muffler,Exhaust Manifold,Exhaust Pipe,Intake Manifold,EGR Tube,Radiator,Water Hose,Fan,Thermostat,Oil Pan,Oil Level Gauge,Oil Filter.
