05-001 TRAVEL ALARM ASSEMBLY STANDARD

05-001 TRAVEL ALARM ASSEMBLY STANDARD-Kobelco SK480LC-6E SK480-6S SK480LC-6 SK450-6 Excavator Parts Number Electronic Catalog EPC Manuals

05-001 TRAVEL ALARM ASSEMBLY STANDARD-Kobelco SK480LC-6E SK480-6S SK480LC-6 SK450-6 Excavator Parts Number Electronic Catalog EPC Manuals
05-001 TRAVEL ALARM ASSEMBLY STANDARD-Kobelco SK480LC-6E SK480-6S SK480LC-6 SK450-6 Excavator Parts Number Electronic Catalog EPC Manuals

5 2 PY01P01043D3 CLIP Wire Ties — 188mm Long
4 1 2432R233D2 CLIP 37x12x40mm
2 1 LC53E01003P1 PLATE
1 1 YN53S00003F1 ALARM Assembly
AR LC53E00002F2 ALARM ASSY
3 4 ZM22C08020 BOLT M08x1.25x20mm (Incls. Washer & Lockwasher)
